A multi-lane and four-side-sealing packing machine for powder is a specialized packaging machine designed to efficiently and accurately package powdered products. It is commonly used in industries such as food, pharmaceuticals, and chemicals.
The machine is comprised of servo driven, packing screw, mixing screw, hopper, and storage components.
It uses a screw to feed and make a quantitative measurement of the powders.
The machine was independently invented by the company and is an automatic feeding packing machine for various powders.
It is controlled by a PLC for the entire process and has a tight design.
The machine incorporates the latest international technology for propelling raw materials.
It is primarily used for powder filling and possesses characteristics such as high processing speed, precise measurement, and easy adjustment.
Model | DXDF900 |
Max output | 200pcs/min |
Scope of substance | ≥100mesh |
Bag lanes | 4-6 lines |
Range of measurement | 1-20g(1-40ml) |
Power supply | 380V 50HZ |
Dimension | 1500X1540X2000 mm |
Screw measures weight | 30 KG |
